Rittal TOPLINSKI IZMJENJIVAČ zrak/voda, 24VDC | 3212024
Output classes 375 – 5,000 W. For use in tough environments. Convenient mounting options and flexible water connection options. External mounting or full internal...
VAT-exclusive price: 98.933.475,43 |
VAT-inclusive price: 118.720.170,52 |
Output classes 375 – 5,000 W. For use in tough environments. Convenient mounting options and flexible water connection options. External mounting or full internal mounting possible.
| Product description | SK Air/water heat exchanger, wall-mounted, 0.3 kW, 24 V (DC), Water-carrying parts: copper/brass, WHD: 150 x 300 x 85 mm |
|---|---|
| Design | Water-carrying parts, copper/brass (Cu/CuZn) |
| Colour | RAL 7035 |
| Supply includes | Fully wired ready for connection, drilling template, sealing and assembly parts |
| Total cooling output | L35 W 10 at 200 l/h: 0.3 kW |
| Rated operating voltage | 24 V (DC) |
| Rated current max. | DC: 1.2 A |
| Permissible operating pressure (p. max.) | 1 ‐ 10 bar |
| Duty cycle | 100 % |
| Cooling medium | Water (see Internet for specifications) |
| Water inlet temperature | 1 °C...30 °C |
| Water connections | ⅜" connector sleeve |
| Operating temperature range | 1 °C...70 °C |
| Note | Integral non-return valve for version with e-Comfort controller |
| Dimensions (W x H x D) | 150 x 300 x 85 mm |
| Pre-fuse | Miniature circuit-breaker/fuse: 4 A |
| Setting range | 20 °C...55 °C |
| Protection category to IEC 60 529 | IP 55 |
| Packs of | 1 pc(s) |
| Net weight | 3.038 kg |
| Gross weight | 3.238 kg |
| Customs tariff number | 84158300 |
| EAN | 4028177430921 |
| ETIM 9 / 8 | EC002515 |
| ECLASS 8.0 | 27180712 |
