Schneider Electric IID - diferencijalni zaštitni prekidač - 2P - 16A - 30mA - B EV tip; A9Z51216
Residual current circuit breaker (RCCB), Acti9 iID, 2P, 16A, B-EV (Electric Vehicle) type, 30mA, double terminal...
VAT-exclusive price: 54.128,00 |
VAT-inclusive price: 64.953,60 |
Residual current circuit breaker (RCCB), Acti9 iID, 2P, 16A, B-EV (Electric Vehicle) type, 30mA, double terminal
| Range | Acti9 |
|---|---|
| Product name | Acti9 iID |
| Product or component type | Residual current circuit breaker (RCCB) |
| device short name | IID |
| Device application | Electrical Vehicle charger |
| Poles description | 2P |
| Neutral position | Left |
| [In] rated current | 16 A |
| Network type | AC |
| earth-leakage sensitivity | 30 mA |
| Earth-leakage protection time delay | Instantaneous |
| Earth-leakage protection class | Type B-EV (Electric Vehicle) |
| quality labels |
VDE NF IMQ KEMA |
| Device location in system |
Outgoer Group incomer |
|---|---|
| Network frequency | 50 Hz |
| [Ue] rated operational voltage | 230 V AC 50 Hz |
| rated breaking and making capacity |
Idm 1500 A Im 1500 A |
| rated conditional short-circuit current | 10 kA |
| [Ui] rated insulation voltage | 250 V |
| [Uimp] rated impulse withstand voltage | 6 kV |
| Contact position indicator | Yes |
| control type | Toggle |
| local signalling |
Trip indicator ON/OFF indication |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| 9 mm pitches | 8 |
| Height | 88 mm |
| Width | 72 mm |
| Depth | 79 mm |
| Net weight | 350 g |
| colour | White |
| Mechanical durability | 20000 cycles |
| electrical durability | 15000 cycles |
| Locking options description | Padlocking device |
| connections - terminals |
Double terminal front 1…35 mm² rigid Double terminal front 1…25 mm² flexible Double terminal front 1…25 mm² flexible with ferrule Double terminal back 1…25 mm² rigid Double terminal back 1…16 mm² flexible Double terminal back 1…16 mm² flexible with ferrule |
| wire stripping length | 14 mm for top or bottom connection |
| tightening torque | 3.5 N.m top or bottom |
| standards |
IEC 61008-2-1 IEC/EN 62423 EN 61008-2-1 |
|---|---|
| product certifications |
CCC KC |
| IP degree of protection |
IP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529 |
| IK degree of protection | IK05 |
| pollution degree | 3 |
| overvoltage category | IV |
| electromagnetic compatibility | 8/20 µs impulse withstand, 3 kA conforming to EN/IEC 61008-1 |
| Operating altitude | 0...2000 m |
| ambient air temperature for operation | -25…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8.5 cm |
| Package 1 Width | 7.5 cm |
| Package 1 Length | 10.0 cm |
| Package 1 Weight | 363.0 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 27 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 11.88 kg |
-
EVlink Parking A9Z51216
