Schneider Electric Schneider Limiter LUA

Current limiter disconnector, TeSys U, 32A/690V, activation 50kA, Iq 130kA@440V, mounting on power base...

Brand: Schneider Electric
Product Code: LUALB1
Availability: Check availability

VAT-exclusive price: 8.297,00

VAT-inclusive price: 9.956,40

Qnt:

Current limiter disconnector, TeSys U, 32A/690V, activation 50kA, Iq 130kA@440V, mounting on power base

Complementary
[Ith] conventional free air thermal current	32 A
breaking capacity	70 kA at 690 V 130 kA at 440 V
[Ui] rated insulation voltage	690 V conforming to EN 60947-1 690 V conforming to IEC 60947-1
Mounting mode	Direct
connections - terminals	Connector 1 x 1…10 mm² flexible without cable end Connector 1 x 1…6 mm² flexible with cable end Connector 2 x 1…6 mm² flexible with cable end Connector 2 x 1…6 mm² flexible without cable end Connector 1 x 1.5…10 mm² solid Connector 2 x 1.5…6 mm² solid
tightening torque	1.9…2.5 N.m flat Ø 6 mm 1.9…2.5 N.m Philips No 2
Net weight	0.31 kg

Offer Sustainability
Sustainable offer status	Green Premium product
REACh Regulation	REACh Declaration
REACh free of SVHC	Yes
EU RoHS Directive	Compliant EU RoHS Declaration
Toxic heavy metal free	Yes
Mercury free	Yes
RoHS exemption information	Yes
China RoHS Regulation	China RoHS declaration
Environmental Disclosure	Product Environmental Profile
WEEE	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
