Schneider Electric Solid state relej, utični, ulaz 15-30 V DC, izlaz 1-24 V DC, 3.5A;SSL1D03BD
Harmony, Solid state slim relay, 3.5 A, DC switching, input 15...30 V DC, output 1...24 V DC...
VAT-exclusive price: 1.896,00 |
VAT-inclusive price: 2.275,20 |
Harmony, Solid state slim relay, 3.5 A, DC switching, input 15...30 V DC, output 1...24 V DC
| range of product |
Harmony Solid State Relays
|
|
|---|---|---|
| product or component type |
Solid state relay up to 10 A
|
|
| device short name |
SSL
|
|
| network number of phases |
1 phase
|
|
| output switching mode |
DC switching
|
| mounting support |
Socket
|
|
|---|---|---|
| [In] rated current |
3.5 A
|
|
| output voltage |
1...24 V DC
|
|
| [Uc] control circuit voltage |
15...30 V DC
|
|
| contacts type and configuration |
1 NO
|
|
| capacitance unbalance |
1.5 pF input/output
|
|
| minimum switching voltage |
15 V DC turn-on
|
|
| maximum switching voltage |
10 V DC turn-off
|
|
| input current limits |
7 mA
|
|
| input impedance |
3500 Ohm
|
|
| solid state output type |
Mosfet output
DC switching |
|
| load current |
0.001…3.5 A
|
|
| tansient Overvoltage |
30 V DC
|
|
| maximum operating frequency |
500 Hz
|
|
| surge current |
9 A for 10 ms
|
|
| maximum voltage drop |
<0.5 V on-state
|
|
| maximum leakage current |
0.001 mA off-state
|
|
| response time |
0.35 ms (turn-on)
0.08 ms (turn-off) |
|
| overvoltage category |
III
|
|
| width |
5 mm
|
|
| height |
28 mm
|
|
| depth |
15 mm
|
|
| net weight |
0.0041 kg
|
| flame retardance |
V0 conforming to UL 94
|
|
|---|---|---|
| dielectric strength |
2500 V for input/output
|
|
| pollution degree |
2
|
|
| product certifications |
UL
CSA |
|
| marking |
CE
|
|
| ambient air temperature for operation |
-20…80 °C
|
|
| ambient air temperature for storage |
-20…85 °C
|
| Unit Type of Package 1 |
PCE
|
|
|---|---|---|
| Number of Units in Package 1 |
1
|
|
| Package 1 Weight |
5 g
|
|
| Package 1 Height |
1.5 cm
|
|
| Package 1 width |
0.5 cm
|
|
| Package 1 Length |
2.8 cm
|
|
| Unit Type of Package 2 |
BB1
|
|
| Number of Units in Package 2 |
12
|
|
| Package 2 Weight |
64 g
|
-
Zelio Relays SSL1D03BD
