Schneider Electric TeSys GB2 - termomagnetni zaštitni prekidač - 1P - 5 A - Id = 66 A;GB2CB10

Thermal magnetic circuit breaker, TeSys GB2, 1P, 5 A, Icu 2 kA@240 V...

Brand: Schneider Electric
Product Code: GB2CB10
Availability: Check availability

VAT-exclusive price: 4.616,00

VAT-inclusive price: 5.539,20

Qnt:

Description
Specification

Thermal magnetic circuit breaker, TeSys GB2, 1P, 5 A, Icu 2 kA@240 V

Main
range	TeSys
product name	TeSys GB2
device short name	GB2
product or component type	Circuit breaker
device application	Control
poles description	1P
network type	AC/DC
utilisation category	Category A conforming to IEC 60947-2 DC-12 conforming to IEC 60947-5-1 DC-13 conforming to IEC 60947-5-1
network frequency	50/60 Hz conforming to IEC 60947-2
breaking capacity	3 kA Icu at 110 V AC 50/60 Hz conforming to IEC 60947-2 2 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2 1.5 kA Icu at 24 V DC conforming to IEC 60947-2 1 kA Icu at 48 V DC conforming to IEC 60947-2
[Ics] rated service short-circuit breaking capacity	75 % at 110 V AC 50/60 Hz conforming to IEC 60947-2 75 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
trip unit technology	Thermal-magnetic
magnetic tripping current	66 A

Complementary
mounting mode	By clips
mounting support	Rail Plate
mounting position	Horizontal Vertical
control type	Toggle
[In] rated current	5 A
[Ue] rated operational voltage	250 V AC 50/60 Hz conforming to IEC 60947-2 277 V AC 60 Hz conforming to CSA C22.2 No 235 277 V AC 60 Hz conforming to UL 1077 48 V DC
[Uimp] rated impulse withstand voltage	4 kV conforming to IEC 60947-2
power dissipation per pole	2 W
mechanical durability	8000 cycles
electrical durability	8000 cycles
connections - terminals	Connector 1 cable(s) 0.75…6 mm²solid without cable end Connector 2 cable(s) 0.75…4 mm²solid without cable end Connector 1 cable(s) 0.75…4 mm²flexible with cable end Connector 2 cable(s) 0.75…2.5 mm²flexible with cable end
tightening torque	1.2 N.m on connector
mechanical robustness	Shocks: 22 Gn for 20 ms conforming to IEC 60068-2-27 Vibrations: 5 Gn, 5...110 Hz conforming to IEC 60068-2-6
Quantity per set	Set of 6
9 mm pitches	2
height	74 mm
width	15 mm
depth	67 mm

Environment
standards	EN/IEC 60947-1 EN/IEC 60947-2 CSA C22.2 No 235 UL 1077
product certifications	UL CSA
protective treatment	TC
IP degree of protection	IP20 conforming to IEC 60529
ambient air temperature for operation	-20…60 °C
ambient air temperature for storage	-40…80 °C
fire resistance	960 °C conforming to IEC 60695-2-1
operating altitude	3000 m

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	9.5 cm
Package 1 Width	9.5 cm
Package 1 Length	10.5 cm
Package 1 Weight	54.0 g
Unit Type of Package 2	BB1
Number of Units in Package 2	6
Package 2 Height	9.5 cm
Package 2 Width	10.5 cm
Package 2 Length	9.5 cm
Package 2 Weight	340.0 g
Unit Type of Package 3	S02
Number of Units in Package 3	72
Package 3 Height	15.0 cm
Package 3 Width	30.0 cm
Package 3 Length	40.0 cm
Package 3 Weight	4.384 kg

Contractual warranty
Warranty	18 months
