Schneider Electric TeSys GV2 & GV3 - naponski okidač - 110...115 V AC 50Hz;GVAS115
Shunt release (MX), TeSys GV2-GV3, 110-115V AC 50Hz...
VAT-exclusive price: 4.236,00 |
VAT-inclusive price: 5.083,20 |
Shunt release (MX), TeSys GV2-GV3, 110-115V AC 50Hz
| range |
TeSys
|
|
|---|---|---|
| device short name |
GVAS
|
|
| product or component type |
Shunt trip release
|
| range compatibility |
GV2ME
GV2LE GV2L GV2P GV3L GV3P |
|
|---|---|---|
| [Uc] control circuit voltage |
127 V AC 60 Hz
110...115 V AC 50 Hz |
|
| control circuit voltage limits |
0.7...1.1 Un
|
|
| [Ui] rated insulation voltage |
690 V AC conforming to IEC 60947-1
600 V AC conforming to UL 60947-4-1 600 V AC conforming to CSA C22.2 No 60947-4-1 |
|
| threshold tripping voltage |
0.75...0.2 Un
|
|
| inrush power in VA |
14 VA AC
|
|
| inrush power in W |
10.5 W
|
|
| hold-in power consumption in VA |
5 VA AC
|
|
| hold-in power consumption in W |
1.6 W
|
|
| operating time |
10...15 ms conforming to IEC 60947-1
|
|
| on-load factor |
100 %
|
|
| connections - terminals |
Screw clamp terminals 1 cable(s) 1…2.5 mm²solid
Screw clamp terminals 2 cable(s) 1…2.5 mm²solid Screw clamp terminals 1 cable(s) 0.75…2.5 mm²flexible without cable end Screw clamp terminals 2 cable(s) 0.75…2.5 mm²flexible without cable end Screw clamp terminals 1 cable(s) 0.75…1.5 mm²flexible with cable end Screw clamp terminals 2 cable(s) 0.75…1.5 mm²flexible with cable end |
|
| tightening torque |
< 1.4 N.m on screw clamp terminals
|
|
| mechanical durability |
10000 cycles with GV3P and GV3L
30000 cycles with GV2ME and GV2P |
|
| quantity per set |
Set of 10
|
|
| height |
89 mm
|
|
| width |
18 mm
|
|
| depth |
66 mm
|
|
| net weight |
0.105 kg
|
| Unit Type of Package 1 |
PCE
|
|
|---|---|---|
| Number of Units in Package 1 |
1
|
|
| Package 1 Weight |
116 g
|
|
| Package 1 Height |
3.6 cm
|
|
| Package 1 width |
8.3 cm
|
|
| Package 1 Length |
9.1 cm
|
|
| Unit Type of Package 2 |
S01
|
|
| Number of Units in Package 2 |
16
|
|
| Package 2 Weight |
2.037 kg
|
|
| Package 2 Height |
15 cm
|
|
| Package 2 width |
15 cm
|
|
| Package 2 Length |
40 cm
|
| Sustainable offer status |
Green Premium product
|
|
|---|---|---|
| REACh Regulation | ||
| REACh free of SVHC |
Yes
|
|
| EU RoHS Directive |
Compliant
EU RoHS Declaration |
|
| Toxic heavy metal free |
Yes
|
|
| Mercury free |
Yes
|
|
| RoHS exemption information | ||
| China RoHS Regulation |
-
TeSys GV3 GVAS115
