Schneider Electric VIGILOHM IM10-H 110 - 230 VAC;IMD-IM10-H
VIGILOHM IM10-H 110 - 230 VAC...
VAT-exclusive price: 56.555,00 |
VAT-inclusive price: 67.866,00 |
VIGILOHM IM10-H 110 - 230 VAC
| range | Vigilohm |
|---|---|
| device short name | IM10-H |
| product or component type | Insulation monitoring device |
| device application | Hospital |
| earthing system | IT |
| user language |
Italian Spanish Chinese Russian English Portuguese German French |
| network rated voltage |
0…230 V - AC at 50/60 Hz (phase to neutral) 0…100 V - DC |
|---|---|
| type of measurement | Network insulation resistance - measurement range: 1 kOhm...10 MOhm |
| local signalling |
Green indicator light: satisfactory insulation resistance Orange indicator light: below fault threshold |
| threshold setting | Fault: 50...500 kOhm |
| response time | <= 1 s |
| auxiliary supply voltage |
125...250 V DC +/- 15 % 110...230 V AC 50/60 Hz +/- 15 % |
| power consumption in VA | 12 VA |
| measurement voltage | 25 V |
| measurement current | 0…0.2 mA |
| internal impedance | 110 kOhm - AC at 50/60 Hz |
| test function | Manual |
| output contact | 1 C/O standard or fail-safe |
| breaking capacity |
250 V - AC at 6 A 12...24 V - DC at 6 A |
| communication port protocol | - |
| display type | Digital display |
| mounting mode |
Flush-mounted Clip-on |
| mounting support |
Panel DIN rail |
| connections - terminals | Removable screw terminal block0.2…2.5 mm² |
| material | Thermoplastic |
| net weight | 0.25 kg |
| height | 110 mm |
| width | 96 mm |
| depth | 59 mm |
| dielectric strength |
4000 V - AC 5500 V - DC |
|---|---|
| IP degree of protection | Front face: IP52 |
| environmental characteristic |
Exposure to damp heat not in service conforming to IEC 60068-2-30 Exposure to damp heat in service conforming to IEC 60068-2-56 Salt mist conforming to IEC 60068-2-52 |
| pollution degree | 2 |
| type of installation | Indoor |
| standards |
IEC 61010-1 IEC 61557-8 IEC 60364-7-710 IEC 61326-2-4 |
| product certifications |
EAC BV CE DNV |
| ambient air temperature for operation | -25…55 °C |
| ambient air temperature for storage | -40…70 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 426.0 g |
| Package 1 Height | 10.5 cm |
| Package 1 width | 13.5 cm |
| Package 1 Length | 16.5 cm |
| Unit Type of Package 2 | P06 |
| Number of Units in Package 2 | 64 |
| Package 2 Weight | 34.79 kg |
| Package 2 Height | 75 cm |
| Package 2 width | 60 cm |
| Package 2 Length | 80 cm |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 8 |
| Package 3 Weight | 4.075 kg |
| Package 3 Height | 30 cm |
| Package 3 width | 30 cm |
| Package 3 Length | 40 cm |
| Warranty | 18 months |
|---|
