Schneider Electric Profinet communication module;VW3A3627
Profinet communication module...
VAT-exclusive price: 40.771,00 |
VAT-inclusive price: 48.925,20 |
Profinet communication module
| range of product | Altivar |
|---|---|
| product or component type | Communication module |
| range compatibility |
Altivar Process ATV600 Altivar Machine ATV340 except Sercos drives Altivar Machine ATV320 Altivar 32 Altivar Process Modular Altivar Process ATV900 |
|---|---|
| communication port protocol |
Link Layer Discovery Protocol PROFINET |
| electrical connection | 2 connectors RJ45, Ethernet |
| transmission rate | 100 Mbits |
| display type |
1 LED for MS (Module Status) 1 LED for NS (Network Status) 1 LED for TX/RX (Transmit/Receive port 1) 1 LED for TX/RX (Transmit/Receive port 2) |
| bus profile | PROFIdrive |
| net weight | 0.3 kg |
| standards | IEC 61800-7-201 (CiA 402) |
|---|
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 63.0 g |
| Package 1 Height | 4.6 cm |
| Package 1 width | 6.5 cm |
| Package 1 Length | 8.9 cm |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 100 |
| Package 2 Weight | 6.824 kg |
| Package 2 Height | 30.0 cm |
| Package 2 width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| range of product | Altivar |
|---|---|
| product or component type | Communication module |
| range compatibility |
Altivar Process ATV600 Altivar Machine ATV340 except Sercos drives Altivar Machine ATV320 Altivar 32 Altivar Process Modular Altivar Process ATV900 |
|---|---|
| communication port protocol |
Link Layer Discovery Protocol PROFINET |
| electrical connection | 2 connectors RJ45, Ethernet |
| transmission rate | 100 Mbits |
| display type |
1 LED for MS (Module Status) 1 LED for NS (Network Status) 1 LED for TX/RX (Transmit/Receive port 1) 1 LED for TX/RX (Transmit/Receive port 2) |
| bus profile | PROFIdrive |
| net weight | 0.3 kg |
| standards | IEC 61800-7-201 (CiA 402) |
|---|
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 63.0 g |
| Package 1 Height | 4.6 cm |
| Package 1 width | 6.5 cm |
| Package 1 Length | 8.9 cm |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 100 |
| Package 2 Weight | 6.824 kg |
| Package 2 Height | 30.0 cm |
| Package 2 width | 30.0 cm |
| Package 2 Length | 40.0 cm |
